Volume pricing
- 1+ pcs$1.75
- 10+ pcs$1.65
- 100+ pcs$1.56
- 500+ pcs$1.47
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Özellikler
- Threaded Mating Lock
- Rear Panel Wire Connection
- Quick Connect - 0.110 (2.80mm), Solder Eyelet
- Number Of Decks
- 1
- Contact Materials
- Tin
- Wire Gauge Min
- 28 AWG
- Renk
- Green
- Nominal Gerilim
- 160V
- Montaj
- Panel, Wall
- Gerilim
- 300V
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Terminal And Terminal Block Type
- STRIP TERMINAL BLOCK
- Genişlik
- 1.017 25.82mm
- Gender
- Male
- Yayın Yılı
- 2010
- Seri
- COMBICON DFK-MC
- Additional Feature
- PA, 94V-0
- Depth
- 20.4mm
- REACH Uyumluluk Kodu
- not_compliant
- Number Of Levels
- 1
- Pitch
- 0.150 3.81mm
- Yükseklik
- 25.82mm
- Orientation
- Straight
- Sıra Sayısı
- 1
- Terminal
- Solder
- Uzunluk
- 25.82mm
- Safety Approval
- UL
- Akım Değeri
- 8A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Wire Gauge Max
- 16 AWG
- Flammability Rating
- UL94 V-0
- Akım
- 8A
- Weight
- 198.446662g
- Max Current Rating
- 8A
- Housing Material
- Polyamide
- Panel Thickness
- 0.020 ~ 0.157 0.5 ~ 4.0mm
- Pozisyon Sayısı
- 3
- Front Panel Wire Connection
- Header, Male Pins
- Number Of Ways
- 3
- Kurşunsuz
- Lead Free
