Volume pricing
- 1+ pcs$12.92
- 10+ pcs$12.19
- 100+ pcs$11.50
- 500+ pcs$10.85
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Material Flammability Rating
- UL94 V-0
- Max Current Rating
- 8A
- Sıra Sayısı
- 1
- Connector Type
- Screw
- Terminal Stili
- Screw - Rising Cage Clamp
- Fabrika Tedarik Süresi
- 6 Weeks
- Renk
- Green
- Montaj Tipi
- Free Hanging (In-Line)
- Flammability Rating
- UL94 V-0
- Depth
- 16.1mm
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- HTS Kodu
- 8536.69.40.40
- Orientation
- Right Angle
- Gender
- Female
- Contact Mating Finish
- Tin
- ECCN Kodu
- EAR99
- Housing Material
- Polyamide (PA), Nylon
- Wire Gauge Or Range Awg
- 14-30 AWG
- Safety Approval
- UL
- Uzunluk
- 63.73mm
- Wire Gauge Max
- 16 AWG
- Plug Wire Entry
- 180°
- Gerilim
- 300V
- Kurşunsuz
- Lead Free
- Seri
- COMBICON MC
- Max Supply Voltage
- 160V
- Pitch
- 0.150 3.81mm
- Akım Değeri
- 8A
- Özellikler
- Mating Flange
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- RoHS Durumu
- RoHS Compliant
- Additional Feature
- PA, 94V-0
- Nominal Gerilim
- 160V
- Tip
- Plug, Female Sockets
- REACH Uyumluluk Kodu
- unknown
- Number Of Decks
- 1
- Material
- Polyamide
- Number Of Ways
- 14
- Number Of Levels
- 1
