Specifications
- Tip
- Plug, Female Sockets
- RoHS Durumu
- RoHS Compliant
- Nominal Gerilim
- 160V
- Additional Feature
- PA, 94V-0
- Özellikler
- Mating Flange
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- Kurşunsuz
- Lead Free
- Seri
- COMBICON MC
- Max Supply Voltage
- 160V
- Pitch
- 0.150 3.81mm
- Akım Değeri
- 8A
- Kurşunsuz Kodu
- yes
- Akım
- 8A
- Insulation Height
- 0.437 11.10mm
- Weight
- 98.999993g
- Genişlik
- 16.1mm
- Voltageiec
- 320V
- Screw Size
- M2
- Montaj
- Cable, Free Hanging, Panel
- Parça Durumu
- Active
- Yayın Yılı
- 2010
- Number Of Contacts
- 11
- Wire Gauge Min
- 14 AWG
- Number Of Levels
- 1
- Yükseklik
- 16.1mm
- Wire Strip Length
- 7mm
- Number Of Decks
- 1
- Material
- Polyamide
- Number Of Ways
- 11
- Flammability Rating
- UL94 V-0
- Montaj Tipi
- Free Hanging (In-Line)
- Depth
- 16.1mm
- Contact Plating
- Tin
- Terminal Stili
- Screw - Rising Cage Clamp
- Connector Type
- Screw, Socket
- Fabrika Tedarik Süresi
- 11 Weeks
- Renk
- Green
- Max Current Rating
- 8A
- Material Flammability Rating
- UL94 V-0
- Sıra Sayısı
- 1
