Volume pricing
- 1+ pcs$1.73
- 10+ pcs$1.63
- 100+ pcs$1.54
- 500+ pcs$1.45
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj Tipi
- Free Hanging (In-Line)
- Flammability Rating
- UL94 V-0
- Depth
- 10.4mm
- Contact Plating
- Tin
- Lead Pitch
- 3.81mm
- Insulation Materials
- Nylon
- Material Flammability Rating
- UL94 V-0
- Max Current Rating
- 8A
- Sıra Sayısı
- 1
- Connector Type
- Screw, Socket
- Terminal Stili
- Screw - Rising Cage Clamp
- Fabrika Tedarik Süresi
- 7 Weeks
- Renk
- Green
- Wire Gauge Or Range Awg
- 14-30 AWG
- Terminal
- Screw
- Safety Approval
- EN; UL; VDE
- Radyasyon Dayanımı
- No
- Wire Gauge Max
- 30 AWG
- Uzunluk
- 23.65mm
- Gerilim
- 300V
- Plug Wire Entry
- 90°
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- Orientation
- Straight
- Gender
- Female
- ECCN Kodu
- EAR99
- Housing Material
- Polyamide (PA), Nylon
- RoHS Durumu
- RoHS Compliant
- Additional Feature
- PA, 94V-0
- Tip
- Plug, Female Sockets
- Kurşunsuz
- Lead Free
- Seri
- COMBICON MCVR
- Akım Değeri
- 8A
- Pitch
- 0.150 3.81mm
- Max Supply Voltage
- 160V
- Voltage Rated Ac
- 160V
- Voltage Rated Dc
- 160V
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- Stripping Length
- 7mm
- Voltageiec
- 320V
