Specifications
- Tip
- Plug, Female Sockets
- Additional Feature
- STANDARD: UL 94V-0, PA, SAFETY APPROVAL: VDE
- RoHS Durumu
- RoHS Compliant
- Voltage Rated Ac
- 160V
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- Voltage Rated Dc
- 160V
- Kurşunsuz
- Lead Free
- Max Supply Voltage
- 160V
- Pitch
- 0.150 3.81mm
- Akım Değeri
- 8A
- Seri
- COMBICON MCVR
- Kurşunsuz Kodu
- yes
- Akım
- 8A
- Weight
- 99.999994g
- Insulation Height
- 0.752 19.10mm
- Genişlik
- 19.54mm
- Wirecable Gauge
- 16 AWG
- Screw Size
- M2
- Montaj
- Cable, Free Hanging
- Voltageiec
- 320V
- Stripping Length
- 7mm
- Number Of Contacts
- 5
- Wire Gauge Min
- 28 AWG
- Yayın Yılı
- 2001
- Parça Durumu
- Active
- Onay Kuruluşu
- CB, CSA, UL, VDE, cULus
- Number Of Levels
- 1
- Yükseklik
- 19.1mm
- Reach Svhc
- No SVHC
- Thickness
- 15.24mm
- Material
- Polyamide
- Number Of Decks
- 1
- Number Of Ways
- 5
- Depth
- 10.4mm
- Flammability Rating
- UL94 V-0
- Montaj Tipi
- Free Hanging (In-Line)
- Insulation Materials
- Nylon
- Lead Pitch
- 3.81mm
- Contact Plating
- Tin
- Fabrika Tedarik Süresi
- 7 Weeks
