Specifications
- Renk
- Green
- Terminal Stili
- Screw - Rising Cage Clamp
- Connector Type
- Screw, Socket
- Fabrika Tedarik Süresi
- 7 Weeks
- Sıra Sayısı
- 1
- Material Flammability Rating
- UL94 V-0
- Max Current Rating
- 8A
- Lead Pitch
- 3.81mm
- Contact Plating
- Tin
- Insulation Materials
- Nylon
- Flammability Rating
- UL94 V-0
- Montaj Tipi
- Free Hanging (In-Line)
- Depth
- 10.4mm
- Housing Material
- Polyamide (PA), Nylon
- ECCN Kodu
- EAR99
- Gender
- Female
- Orientation
- Straight
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- Wire Gauge Max
- 16 AWG
- Uzunluk
- 12.22mm
- Plug Wire Entry
- 90°
- Gerilim
- 300V
- Safety Approval
- UL
- Radyasyon Dayanımı
- No
- Terminal
- Screw
- Wire Gauge Or Range Awg
- 14-30 AWG
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- Voltage Rated Dc
- 160V
- Voltage Rated Ac
- 160V
- Seri
- COMBICON MCVR
- Max Supply Voltage
- 160V
- Pitch
- 0.150 3.81mm
- Akım Değeri
- 8A
- Kurşunsuz
- Lead Free
- Tip
- Plug, Female Sockets
- RoHS Durumu
- RoHS Compliant
- Additional Feature
- PA, 94V-0
- Thickness
- 7.62mm
- Number Of Levels
- 1
