Volume pricing
- 1+ pcs$1.09
- 10+ pcs$1.03
- 100+ pcs$0.97
- 500+ pcs$0.91
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- Voltage Rated Dc
- 160V
- Voltage Rated Ac
- 160V
- Akım Değeri
- 8A
- Pitch
- 0.150 3.81mm
- Max Supply Voltage
- 160V
- Seri
- COMBICON MCVW
- Kurşunsuz
- Lead Free
- Tip
- Plug, Female Sockets
- RoHS Durumu
- RoHS Compliant
- Thickness
- 11.43mm
- Onay Kuruluşu
- CB, CSA, UL, VDE, cULus
- Number Of Levels
- 1
- Yükseklik
- 12.5mm
- Reach Svhc
- No SVHC
- Number Of Ways
- 4
- Material
- Polyamide
- Number Of Decks
- 1
- Genişlik
- 19.1mm
- Wirecable Gauge
- 28 AWG
- Akım
- 8A
- Kurşunsuz Kodu
- yes
- Weight
- 100.999996g
- Insulation Height
- 0.752 19.10mm
- Number Of Contacts
- 4
- Wire Gauge Min
- 14 AWG
- Yayın Yılı
- 2001
- Parça Durumu
- Active
- Montaj
- Cable, Free Hanging, Plug-In
- Screw Size
- M2
- Stripping Length
- 7mm
- Voltageiec
- 320V
- Renk
- Green
- Fabrika Tedarik Süresi
- 7 Weeks
- Terminal Stili
- Screw - Rising Cage Clamp
- Connector Type
- Screw, Socket
- Sıra Sayısı
- 1
- Max Current Rating
- 8A
- Material Flammability Rating
- UL94 V-0
- Insulation Materials
- Nylon
