Volume pricing
- 1+ pcs$5.76
- 10+ pcs$5.43
- 100+ pcs$5.13
- 500+ pcs$4.84
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Kurşunsuz
- Lead Free
- Currentul
- 15A
- Seri
- COMBICON SMSTB
- Max Supply Voltage
- 250V
- Pitch
- 0.200 5.08mm
- Akım Değeri
- 12A
- Özellikler
- Retention Latches (Non-Wire Side)
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- RoHS Durumu
- RoHS Compliant
- Nominal Gerilim
- 250V
- Additional Feature
- PA, 94V-0
- Tip
- Plug, Female Sockets
- REACH Uyumluluk Kodu
- unknown
- Number Of Decks
- 1
- Wire Cross Section
- 2.5 mm2
- Material
- Polyamide
- Number Of Ways
- 12
- Yükseklik
- 25.6mm
- Number Of Levels
- 1
- Onay Kuruluşu
- CSA, UL, cULus
- Stripping Length
- 7mm
- Voltageiec
- 630V
- Montaj
- Cable, Free Hanging, Plug-In
- Screw Size
- M3
- Parça Durumu
- Active
- Yayın Yılı
- 2003
- Wire Gauge Min
- 24 AWG
- Number Of Contacts
- 12
- Insulation Height
- 0.610 15.49mm
- Weight
- 131g
- Kurşunsuz Kodu
- yes
- Akım
- 10A
- Genişlik
- 25.6mm
- Max Current Rating
- 12A
- Material Flammability Rating
- UL94 V-0
- Sıra Sayısı
- 1
- Connector Type
- Screw, Socket
- Terminal Stili
- Screw - Rising Cage Clamp
- Fabrika Tedarik Süresi
- 7 Weeks
- Renk
- Green
