Specifications
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Özellikler
- Mating Flange
- Gerilim
- 300V
- Montaj
- Free Hanging, Panel, Plug-In
- Screw Size
- M3
- Terminal
- Screw
- Orientation
- Right Angle
- Uzunluk
- 91.4mm
- Contact Plating
- Tin
- Seri
- COMBICON IC
- Depth
- 19.2mm
- Additional Feature
- PA, 94V-0
- Material
- Polyamide
- Weight
- 137.000006g
- Max Current Rating
- 12A
- Akım Değeri
- 12A
- Wire Gauge Max
- 30 AWG
- Connector Type
- Plug, Screw
- Voltageiec
- 630V
- RoHS Durumu
- RoHS Compliant
- Fabrika Tedarik Süresi
- 7 Weeks
- HTS Kodu
- 8536.69.40.40
- Housing Material
- Polyamide (PA), Nylon
- Onay Kuruluşu
- CB, CSA, UL, VDE
- Kurşunsuz
- Lead Free
- Wire Gauge Or Range Awg
- 12-30 AWG
- Genişlik
- 91.4mm
- Wire Strip Length
- 7mm
- Wire Gauge Min
- 12 AWG
- Number Of Decks
- 1
- Montaj Tipi
- Free Hanging (In-Line)
- Material Flammability Rating
- UL94 V-0
- Renk
- Green
- Nominal Gerilim
- 250V
- Sıra Sayısı
- 1
- Radyasyon Dayanımı
- No
- Yükseklik
- 19.2mm
- Pitch
- 0.200 5.08mm
- Number Of Levels
- 1
