Volume pricing
- 1+ pcs$1.84
- 10+ pcs$1.74
- 100+ pcs$1.64
- 500+ pcs$1.55
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Seri
- COMBICON IC
- Contact Plating
- Tin
- Depth
- 15mm
- Orientation
- Right Angle
- Terminal
- Screw
- Uzunluk
- 11.66mm
- Özellikler
- Mating Flange
- Gerilim
- 300V
- Montaj
- Free Hanging, Panel, Plug-In
- Screw Size
- M3
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Housing Material
- Polyamide (PA), Nylon
- HTS Kodu
- 8536.69.40.40
- Wire Gauge Or Range Awg
- 12-30 AWG
- Kurşunsuz
- Lead Free
- RoHS Durumu
- RoHS Compliant
- Connector Type
- Plug, Screw
- Voltageiec
- 630V
- Fabrika Tedarik Süresi
- 7 Weeks
- Akım Değeri
- 12A
- Wire Gauge Max
- 30 AWG
- Material
- Polyamide
- Max Current Rating
- 12A
- Weight
- 137.000006g
- Plug Wire Entry
- 180°
- Gender
- Female
- Yayın Yılı
- 2011
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Ambalaj
- Bulk
- Yükseklik
- 19.2mm
- Pitch
- 0.200 5.08mm
- Number Of Levels
- 1
- Safety Approval
- UL; CSA
- Montaj Tipi
- Free Hanging (In-Line)
- Wire Strip Length
- 7mm
- Wire Gauge Min
- 12 AWG
- Renk
- Green
- Nominal Gerilim
- 250V
- Material Flammability Rating
- UL94 V-0
