Volume pricing
- 1+ pcs$0.45
- 10+ pcs$0.43
- 100+ pcs$0.40
- 500+ pcs$0.38
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Max
- 14 AWG
- Ambalaj
- Bulk
- Akım Değeri
- 12A
- Housing Material
- Polyamide (PA), Nylon
- Voltageiec
- 630V
- Plug Wire Entry
- 180°
- Montaj Tipi
- Free Hanging (In-Line)
- Connector Type
- Crimp
- ECCN Kodu
- EAR99
- Wire Gauge Or Range Mm
- 0.5-2.5mm2
- Tip
- Plug Housing for Male Pins
- Flammability Rating
- UL94 V-0
- Özellikler
- Locking Ramp
- Yayın Yılı
- 2011
- Max Current Rating
- 12A
- Pitch
- 0.200 5.08mm
- Montaj
- Cable, Free Hanging
- Wire Gauge Min
- 20 AWG
- Wire Gauge Or Range Awg
- 14-20 AWG
- Gerilim
- 300V
- Wire Cross Section
- 2.5 mm2
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 4 Weeks
- Sıra Sayısı
- 1
- Kurşunsuz Kodu
- yes
- Material Flammability Rating
- UL94 V-0
- Contact Plating
- Tin
- Insulation Height
- 0.417 10.60mm
- Nominal Gerilim
- 250V
- Number Of Ways
- 4
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Orientation
- Straight
- Number Of Positions Per Level
- 4
- Akım
- 10A
- Number Of Levels
- 1
- Safety Approval
- UL
- Seri
- COMBICON ICC
- Number Of Decks
- 1
- Pozisyon Sayısı
- 4
