Specifications
- HTS Kodu
- 8536.69.40.40
- Parça Durumu
- Active
- Ambalaj
- Bulk
- Insulation Height
- 0.591 15.00mm
- Özellikler
- Ejector Latches
- Housing Material
- Polyamide (PA), Nylon
- Renk
- Green
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Flammability Rating
- UL94 V-0
- Seri
- COMBICON MSTB
- ECCN Kodu
- EAR99
- Tip
- Plug, Female Sockets
- Yayın Yılı
- 2012
- Currentiec
- 12A
- Wire Gauge Or Range Awg
- 12-30 AWG
- Montaj Tipi
- Free Hanging (In-Line)
- Nominal Gerilim
- 250V
- Pitch
- 0.200 5.08mm
- Onay Kuruluşu
- cULus
- Number Of Positions Per Level
- 15
- Terminal Stili
- Screw - Rising Cage Clamp
- RoHS Durumu
- RoHS Compliant
- Voltageiec
- 630V
- Kurşunsuz Kodu
- yes
- Akım
- 15A
- Montaj
- Free Hanging
- Fabrika Tedarik Süresi
- 6 Weeks
- Material Flammability Rating
- UL94 V-0
- Wire Strip Length
- 7mm
- Plug Wire Entry
- 180°
- Gerilim
- 300V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Wire Gauge Min
- 24 AWG
- Akım Değeri
- 12A
- REACH Uyumluluk Kodu
- unknown
- Screw Size
- M3
- Contact Mating Finish
- Tin
- Number Of Levels
- 1
- Connector Type
- Screw
- Wire Gauge Max
- 12 AWG
