Volume pricing
- 1+ pcs$2.00
- 10+ pcs$1.89
- 100+ pcs$1.78
- 500+ pcs$1.68
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Levels
- 1
- Contact Mating Finish
- Tin
- Connector Type
- Screw
- Wire Gauge Max
- 30 AWG
- Screw Size
- M3
- Gender
- Male
- Akım Değeri
- 12A
- REACH Uyumluluk Kodu
- unknown
- Wire Gauge Min
- 12 AWG
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Plug Wire Entry
- 180°
- Gerilim
- 300V
- Orientation
- Straight
- Wire Strip Length
- 7mm
- Material Flammability Rating
- UL94 V-0
- Material
- Polyamide
- Montaj
- Cable, Free Hanging
- Fabrika Tedarik Süresi
- 4 Weeks
- Depth
- 15.5mm
- Kurşunsuz Kodu
- yes
- Voltageiec
- 630V
- Akım
- 15A
- Kurşunsuz
- Lead Free
- RoHS Durumu
- RoHS Compliant
- Terminal Stili
- Screw - Rising Cage Clamp
- Genişlik
- 29.3mm
- Montaj Tipi
- Free Hanging (In-Line)
- Nominal Gerilim
- 250V
- Pitch
- 0.200 5.08mm
- Onay Kuruluşu
- cULus
- Number Of Positions Per Level
- 2
- Yayın Yılı
- 2012
- Currentiec
- 12A
- Wire Gauge Or Range Awg
- 12-30 AWG
- Tip
- Plug, Female Sockets
- ECCN Kodu
- EAR99
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Flammability Rating
- UL94 V-0
- Seri
- COMBICON MSTB
- Renk
- Green
