Volume pricing
- 1+ pcs$1.32
- 10+ pcs$1.24
- 100+ pcs$1.17
- 500+ pcs$1.11
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Mating Finish
- Tin
- Akım Değeri
- 20A
- Safety Approval
- BV; CSA; CUL; DNV; EAC; GL; LR
- Weight
- 5.010013g
- Connector Type
- Plug
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Ambalaj
- Bulk
- Insulation Height
- 1.142 29.00mm
- Renk
- Green
- Yayın Yılı
- 1998
- Number Of Ways
- 2
- Additional Feature
- STANDARD: UL 94V-0, PA, SAFETY APPROVAL: RS; UL
- Sıra Sayısı
- 1
- Pitch
- 0.300 7.62mm
- Max Current Rating
- 20A
- Number Of Decks
- 1
- Header Orientation
- Vertical
- Number Of Poles
- 2
- Akım
- 20A
- Number Of Levels
- 1
- RoHS Durumu
- RoHS Compliant
- Contact Materials
- Copper
- Contact Tail Length
- 0.197 5.00mm
- Seri
- COMBICON PCV
- Voltage Rated Ac
- 400V
- Orientation
- Straight
- Onay Kuruluşu
- CSA, UL
- Fastening Method
- CONNECTOR
- Terminal Stili
- Solder
- Yükseklik
- 15.22mm
- HTS Kodu
- 8536.69.40.40
- Genişlik
- 50mm
- Nominal Gerilim
- 400V
- Gerilim
- 300V
- Kurşunsuz
- Lead Free
- Voltageiec
- 630V
- Material Flammability Rating
- UL94 V-0
- Flammability Rating
- UL94 V-0
- Fabrika Tedarik Süresi
- 7 Weeks
