Specifications
- Parça Durumu
- Active
- Ambalaj
- Bulk
- Insulation Height
- 0.437 11.10mm
- Renk
- Green
- Yayın Yılı
- 2001
- Number Of Ways
- 10
- Voltage Rated Dc
- 160V
- Screw Size
- M2
- Akım Değeri
- 8A
- Safety Approval
- UL
- Plug Wire Entry
- 180°
- Weight
- 97.999992g
- Terminal
- Screw
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Connector Type
- Screw, Socket
- Thickness
- 34.29mm
- Number Of Decks
- 1
- Contact Plating
- Tin
- Akım
- 8A
- Radyasyon Dayanımı
- No
- Additional Feature
- PA, 94V-0
- Sıra Sayısı
- 1
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- Pitch
- 0.150 3.81mm
- Wire Gauge Max
- 16 AWG
- Reach Svhc
- No SVHC
- Max Current Rating
- 8A
- Stripping Length
- 7mm
- Seri
- COMBICON MC
- Wire Gauge Min
- 28 AWG
- Voltage Rated Ac
- 160V
- Orientation
- Right Angle
- Onay Kuruluşu
- CB, CSA, UL, VDE, cULus
- Terminal Stili
- Screw - Rising Cage Clamp
- Number Of Levels
- 1
- Material
- Nylon
- Number Of Contacts
- 10
- RoHS Durumu
- RoHS Compliant
- Housing Material
- Polyamide (PA), Nylon
- Kurşunsuz Kodu
- yes
