Specifications
- Akım
- 8A
- Thickness
- 22.86mm
- Number Of Decks
- 1
- Contact Plating
- Tin
- Wire Gauge Max
- 16 AWG
- Max Current Rating
- 8A
- Stripping Length
- 7mm
- Additional Feature
- PA, 94V-0
- Sıra Sayısı
- 1
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- Pitch
- 0.150 3.81mm
- Yayın Yılı
- 2001
- Number Of Ways
- 7
- Screw Size
- M2
- Voltage Rated Dc
- 160V
- Parça Durumu
- Active
- Ambalaj
- Bulk
- Insulation Height
- 0.437 11.10mm
- Renk
- Green
- Terminal
- Screw
- Weight
- 97.999992g
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Connector Type
- Screw, Socket
- Akım Değeri
- 8A
- Plug Wire Entry
- 180°
- Safety Approval
- UL
- Montaj
- Cable, Free Hanging, Plug-In
- Housing Material
- Polyamide (PA), Nylon
- Montaj Tipi
- Free Hanging (In-Line)
- Kurşunsuz Kodu
- yes
- Depth
- 16.1mm
- ECCN Kodu
- EAR99
- Voltageiec
- 320V
- Material Flammability Rating
- UL94 V-0
- Gender
- Female
- Flammability Rating
- UL94 V-0
- Fabrika Tedarik Süresi
- 5 Weeks
- Max Supply Voltage
- 160V
- Uzunluk
- 27.46mm
- Wire Gauge Or Range Awg
- 14-30 AWG
