Volume pricing
- 1+ pcs$11.98
- 10+ pcs$11.30
- 100+ pcs$10.66
- 500+ pcs$10.06
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge Or Range Awg
- 12-24 AWG
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Akım Değeri
- 12A
- Fabrika Tedarik Süresi
- 6 Weeks
- Wire Strip Length
- 7mm
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Yayın Yılı
- 2012
- Tip
- Plug, Female Sockets
- Voltageiec
- 1kV
- Renk
- Green
- RoHS Durumu
- RoHS Compliant
- Kurşunsuz Kodu
- yes
- Connector Type
- Screw
- Contact Mating Finish
- Tin
- Montaj
- Free Hanging
- Material Flammability Rating
- UL94 V-0
- Montaj Tipi
- Free Hanging (In-Line)
- Wire Gauge Max
- 12 AWG
- Nominal Gerilim
- 400V
- REACH Uyumluluk Kodu
- not_compliant
- Wire Gauge Min
- 24 AWG
- Ambalaj
- Bulk
- Insulation Height
- 0.591 15.00mm
- Housing Material
- Polyamide (PA), Nylon
- Number Of Levels
- 1
- Akım
- 12A
- Screw Size
- M3
- Gerilim
- 400V
- Seri
- COMBICON GMSTB
- Plug Wire Entry
- 180°
- Özellikler
- Explosion Proof, Mating Flange
- Pozisyon Sayısı
- 8
- Pitch
- 0.300 7.62mm
- Terminal Stili
- Screw - Rising Cage Clamp
