Volume pricing
- 1+ pcs$8.06
- 10+ pcs$7.60
- 100+ pcs$7.17
- 500+ pcs$6.77
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Connector Type
- Screw
- Renk
- Green
- Voltageiec
- 630V
- Tip
- Plug, Female Sockets
- RoHS Durumu
- RoHS Compliant
- Montaj
- Free Hanging, Panel
- Orientation
- Right Angle
- Contact Mating Finish
- Tin
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Akım Değeri
- 12A
- Wire Gauge Or Range Awg
- 12-24 AWG
- Yayın Yılı
- 2012
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Wire Strip Length
- 7mm
- Fabrika Tedarik Süresi
- 6 Weeks
- Plug Wire Entry
- 180°
- Özellikler
- Explosion Proof, Mating Flange
- Number Of Levels
- 1
- Seri
- COMBICON MSTB
- Gerilim
- 250V
- Screw Size
- M3
- Akım
- 12A
- ECCN Kodu
- EAR99
- Terminal Stili
- Screw - Rising Cage Clamp
- Pitch
- 0.200 5.08mm
- Nominal Gerilim
- 250V
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Max
- 12 AWG
- Number Of Positions Per Level
- 8
- Max Current Rating
- 12A
- Montaj Tipi
- Free Hanging (In-Line)
- Housing Material
- Polyamide (PA), Nylon
- Insulation Height
- 0.591 15.00mm
- Ambalaj
- Bulk
- Wire Gauge Min
- 24 AWG
