Volume pricing
- 1+ pcs$17.43
- 10+ pcs$16.45
- 100+ pcs$15.52
- 500+ pcs$14.64
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 6 Weeks
- Nominal Gerilim
- 250V
- Pozisyon Sayısı
- 19
- Number Of Decks
- 1
- HTS Kodu
- 8536.69.40.40
- Terminal Stili
- Screw - Rising Cage Clamp
- Kurşunsuz Kodu
- yes
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Max
- 30 AWG
- Number Of Contacts
- 19
- Contact Mating Finish
- Tin
- Safety Approval
- UL
- Montaj Tipi
- Free Hanging (In-Line)
- Screw Size
- M3
- ECCN Kodu
- EAR99
- Voltageiec
- 630V
- Uzunluk
- 7mm
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Akım
- 15A
- Number Of Ways
- 19
- Plug Wire Entry
- 270°
- Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Awg
- 12-30 AWG
- Gerilim
- 300V
- Seri
- COMBICON MVSTBW
- Number Of Levels
- 1
- Wire Gauge Min
- 24 AWG
- Orientation
- Straight
- RoHS Durumu
- RoHS Compliant
- Additional Feature
- PA, 94V-0
- Parça Durumu
- Active
- Montaj
- Cable, Free Hanging
- Terminal
- Screw
- Özellikler
- Retention Latches (Non-Wire Side)
- Ambalaj
- Bulk
- Pitch
- 0.200 5.08mm
- Wire Cross Section
- 2.5 mm2
- Tip
- Plug, Female Sockets
- Sıra Sayısı
- 1
- Weight
- 133.000002g
