Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Decks
- 1
- Kurşunsuz Kodu
- yes
- Genişlik
- 26mm
- Terminal Stili
- Screw - Rising Cage Clamp
- Safety Approval
- UL
- Screw Size
- M3
- Montaj Tipi
- Free Hanging (In-Line)
- Akım
- 15A
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Plug Wire Entry
- 270°
- Wire Gauge Or Range Awg
- 12-30 AWG
- Voltage Rated Ac
- 320V
- Seri
- COMBICON MVSTBW
- Connector Type
- Socket
- Parça Durumu
- Active
- Özellikler
- Retention Latches (Non-Wire Side)
- Terminal
- Screw
- Ambalaj
- Bulk
- Pitch
- 0.200 5.08mm
- Wire Cross Section
- 2.5 mm2
- Material
- Nylon
- Wirecable Gauge
- 24 AWG
- Max Supply Voltage
- 250V
- Sıra Sayısı
- 1
- Weight
- 133.000002g
- Housing Material
- Polyamide (PA), Nylon
- Yayın Yılı
- 2001
- Lead Pitch
- 5.08mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Renk
- Green
- Akım Değeri
- 12A
- Fabrika Tedarik Süresi
- 7 Weeks
- Nominal Gerilim
- 250V
- Depth
- 12.6mm
- Stripping Length
- 7mm
- Number Of Contacts
- 4
- Wire Gauge Max
- 24 AWG
- Material Flammability Rating
- UL94 V-0
- Gender
- Male
- Onay Kuruluşu
- CB, CSA, UL, VDE
