Volume pricing
- 1+ pcs$5.56
- 10+ pcs$5.25
- 100+ pcs$4.95
- 500+ pcs$4.67
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Connector Type
- Socket
- Parça Durumu
- Active
- Additional Feature
- PA, 94V-0
- Ambalaj
- Bulk
- Terminal
- Screw
- Özellikler
- Retention Latches (Non-Wire Side)
- Material
- Polyamide
- Pitch
- 0.197 5.00mm
- Weight
- 1.59982kg
- Sıra Sayısı
- 1
- Max Supply Voltage
- 250V
- Yayın Yılı
- 2010
- Housing Material
- Polyamide (PA), Nylon
- Renk
- Green
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Akım Değeri
- 12A
- Terminal Stili
- Screw - Rising Cage Clamp
- Kurşunsuz Kodu
- yes
- Genişlik
- 26mm
- Number Of Decks
- 1
- Montaj Tipi
- Free Hanging (In-Line)
- Screw Size
- M3
- Safety Approval
- UL
- Plug Wire Entry
- 270°
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Akım
- 15A
- Wire Gauge Or Range Awg
- 12-30 AWG
- Seri
- COMBICON MVSTBW
- Orientation
- Straight
- Wire Gauge Min
- 12 AWG
- Number Of Levels
- 1
- RoHS Durumu
- RoHS Compliant
- Contact Plating
- Tin
- Montaj
- Cable, Free Hanging
- Tip
- Plug, Female Sockets
- Radyasyon Dayanımı
- No
- Insulation Height
- 0.496 12.60mm
- Yükseklik
- 25mm
- Max Current Rating
- 12A
- Fabrika Tedarik Süresi
- 7 Weeks
