Volume pricing
- 1+ pcs$12.32
- 10+ pcs$11.62
- 100+ pcs$10.96
- 500+ pcs$10.34
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Cross Section
- 2.5 mm2
- Pitch
- 0.200 5.08mm
- Sıra Sayısı
- 1
- Weight
- 132.000001g
- Yayın Yılı
- 2003
- Housing Material
- Polyamide (PA), Nylon
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Renk
- Green
- Akım Değeri
- 12A
- REACH Uyumluluk Kodu
- not_compliant
- Connector Type
- Screw, Socket
- Additional Feature
- PA, 94V-0
- Parça Durumu
- Active
- Terminal
- Screw
- Özellikler
- Retention Latches (Wire Side)
- Ambalaj
- Bulk
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Akım
- 15A
- Plug Wire Entry
- 90°
- Wire Gauge Or Range Awg
- 12-30 AWG
- Seri
- COMBICON MVSTBR
- Pozisyon Sayısı
- 15
- Number Of Decks
- 1
- Terminal Stili
- Screw - Rising Cage Clamp
- Genişlik
- 77.2mm
- Kurşunsuz Kodu
- yes
- Safety Approval
- UL
- Montaj Tipi
- Free Hanging (In-Line)
- Screw Size
- M3
- Tip
- Plug, Female Sockets
- Insulation Height
- 1.024 26.01mm
- Yükseklik
- 26mm
- Max Current Rating
- 12A
- Number Of Levels
- 1
- Wire Gauge Min
- 12 AWG
- Orientation
- Straight
- RoHS Durumu
- RoHS Compliant
- Contact Plating
- Tin
- Montaj
- Cable, Free Hanging
- ECCN Kodu
- EAR99
