Specifications
- Pitch
- 0.138 3.50mm
- Tip
- Plug, Female Sockets
- Sıra Sayısı
- 2
- Yayın Yılı
- 2011
- Housing Material
- Polyamide (PA), Nylon
- Insulation Height
- 0.522 13.25mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Renk
- Green
- Akım Değeri
- 8A
- Wire Strip Length
- 10mm
- Number Of Levels
- 2
- Wire Gauge Min
- 16 AWG
- RoHS Durumu
- RoHS Compliant
- Connector Type
- Screw
- Additional Feature
- STANDARD: UL 94V-0, PA
- Parça Durumu
- Active
- Montaj
- Free Hanging
- Terminal
- Screwless
- Özellikler
- Ejector Latches
- Ambalaj
- Bulk
- Fastening Method
- SPRING LOADED
- ECCN Kodu
- EAR99
- Number Of Positions Per Level
- 10
- Voltageiec
- 250V
- Wire Gauge Or Range Mm
- 0.2-1.5mm2
- Akım
- 8A
- Number Of Ways
- 10
- Plug Wire Entry
- 180°
- Kurşunsuz
- Lead Free
- Wire Gauge Or Range Awg
- 16-24 AWG
- Gerilim
- 150V
- Seri
- COMBICON DFMC
- Fabrika Tedarik Süresi
- 17 Weeks
- Nominal Gerilim
- 160V
- Pozisyon Sayısı
- 20
- Number Of Decks
- 1
- HTS Kodu
- 8536.69.40.40
- Terminal Stili
- Screwless - Push-In Spring
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Max
- 24 AWG
