Volume pricing
- 1+ pcs$0.25
- 10+ pcs$0.23
- 100+ pcs$0.22
- 500+ pcs$0.21
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fastening Method
- SPRING LOADED
- Ambalaj
- Bulk
- Terminal
- Solder
- Montaj
- Through Hole
- Özellikler
- Interlocking (Side), Lever Actuated
- Parça Durumu
- Active
- Additional Feature
- POLYAMIDE, 94V-2
- Mating Orientation
- Vertical with Board
- RoHS Durumu
- RoHS Compliant
- Orientation
- Straight
- Wire Gauge Min
- 16 AWG
- Wire Gauge
- 16-22 AWG
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Renk
- Green
- Akım Değeri
- 15A
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Yükseklik
- 12.7mm
- Max Current Rating
- 15A
- Yayın Yılı
- 2010
- Housing Material
- Polyamide (PA), Nylon
- Radyasyon Dayanımı
- No
- Weight
- 1.120005g
- Max Supply Voltage
- 320V
- Pitch
- 5.08mm
- Montaj Tipi
- Through Hole
- Onay Kuruluşu
- CB, CSA, KEMA, UL
- Safety Approval
- UL; CSA
- Wire Gauge Max
- 24 AWG
- Number Of Contacts
- 1
- Stripping Length
- 10mm
- Kurşunsuz Kodu
- yes
- Genişlik
- 17mm
- HTS Kodu
- 8536.69.40.40
- Depth
- 12.7mm
- Fabrika Tedarik Süresi
- 7 Weeks
- Nominal Gerilim
- 320V
- Gerilim
- 300V
- Seri
- COMBICON FFKDS
- Wire Termination
- Screwless - Spring Cage, Tension Clamp
- Flammability Rating
- UL94 V-2
