Volume pricing
- 1+ pcs$2.70
- 10+ pcs$2.55
- 100+ pcs$2.40
- 500+ pcs$2.27
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Renk
- Green
- Onay Kuruluşu
- CB, CSA, UL, VDE
- Terminal Stili
- Screw
- Gender
- Female
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Fabrika Tedarik Süresi
- 7 Weeks
- Tip
- Receptacle, Male Pins
- Insulation Height
- 0.681 17.30mm
- Number Of Decks
- 1
- Nominal Gerilim
- 320V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Safety Approval
- UL
- Orientation
- Straight
- Material
- Polyamide
- Sıra Sayısı
- 1
- Screw Size
- M3
- Kurşunsuz Kodu
- yes
- Number Of Positions Per Level
- 4
- Flammability Rating
- UL94 V-2
- Yayın Yılı
- 2011
- Depth
- 17.3mm
- Montaj
- Cable
- Pitch
- 0.200 5.08mm
- Seri
- COMBICON MVSTBU
- Contact Plating
- Tin
- Wire Cross Section
- 2.5 mm2
- Material Flammability Rating
- UL94 V-0
- Wire Strip Length
- 7mm
- Uzunluk
- 21.84mm
- Max Current Rating
- 12A
- Özellikler
- Mounting Flange
- Genişlik
- 17.3mm
- Radyasyon Dayanımı
- No
- Max Supply Voltage
- 320V
- Number Of Levels
- 1
- Housing Material
- Polyamide (PA), Nylon
- Voltageiec
- 630V
- Montaj Tipi
- Board Mount
- Gerilim
- 300V
