Specifications
- Yükseklik
- 18.2mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz
- Lead Free
- Max Current Rating
- 12A
- Renk
- Green
- Voltageiec
- 630V
- RoHS Durumu
- RoHS Compliant
- Material Flammability Rating
- UL94 V-0
- Sıra Sayısı
- 1
- Montaj Tipi
- Free Hanging (In-Line)
- Özellikler
- Mating Flange
- Parça Durumu
- Active
- Wire Cross Section
- 2.5 mm2
- Wire Gauge Min
- 12 AWG
- ECCN Kodu
- EAR99
- Ambalaj
- Bulk
- Tip
- Plug, Female Sockets
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Insulation Height
- 0.591 15.00mm
- Additional Feature
- PA, 94V-0
- Pitch
- 0.197 5.00mm
- Number Of Decks
- 1
- Housing Material
- Polyamide (PA), Nylon
- Montaj
- Free Hanging, Panel
- Wire Gauge Or Range Awg
- 12-30 AWG
- Nominal Gerilim
- 250V
- Number Of Ways
- 3
- Plug Wire Entry
- 180°
- Seri
- COMBICON MSTB
- Orientation
- Right Angle
- Kurşunsuz Kodu
- yes
- Terminal
- Screw
- Connector Type
- Screw, Socket
- Terminal Stili
- Screw - Rising Cage Clamp
- Currentul
- 15A
- Contact Plating
- Tin
- Screw Size
- M3
- Yayın Yılı
- 2010
- Gerilim
- 300V
- Fabrika Tedarik Süresi
- 6 Weeks
