Volume pricing
- 1+ pcs$4.85
- 10+ pcs$4.58
- 100+ pcs$4.32
- 500+ pcs$4.07
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Parça Durumu
- Active
- Connector Type
- Screw
- Terminal Stili
- Screw - Rising Cage Clamp
- Wire Gauge Min
- 12 AWG
- Material Flammability Rating
- UL94 V-0
- Montaj Tipi
- Free Hanging (In-Line)
- Özellikler
- Retention Latches (Wire Side)
- Voltageiec
- 630V
- Pozisyon Sayısı
- 3
- RoHS Durumu
- RoHS Compliant
- Seri
- COMBICON MVSTBR
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Mating Finish
- Gold
- Renk
- Green
- Wire Gauge Max
- 30 AWG
- Akım Değeri
- 12A
- Montaj
- Free Hanging
- Akım
- 15A
- Wire Gauge Or Range Awg
- 12-30 AWG
- Nominal Gerilim
- 250V
- Flammability Rating
- UL94 V-0
- Plug Wire Entry
- 90°
- REACH Uyumluluk Kodu
- not_compliant
- Wire Strip Length
- 7mm
- Housing Material
- Polyamide (PA), Nylon
- Number Of Levels
- 1
- Fabrika Tedarik Süresi
- 4 Weeks
- Pitch
- 0.200 5.08mm
- Weight
- 6.179998g
- ECCN Kodu
- EAR99
- Ambalaj
- Bulk
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Screw Size
- M3
- Tip
- Plug, Female Sockets
- Yayın Yılı
- 2011
- Gerilim
- 300V
- Insulation Height
- 1.024 26.01mm
