Volume pricing
- 1+ pcs$0.67
- 10+ pcs$0.63
- 100+ pcs$0.60
- 500+ pcs$0.56
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Uzunluk
- 12.16mm
- Depth
- 10.2mm
- Weight
- 165.000008g
- Number Of Decks
- 1
- Number Of Positions Per Level
- 2
- Pitch
- 0.200 5.08mm
- Additional Feature
- STANDARD: UL 94V-0, PA, SAFETY APPROVAL: VDE
- Fabrika Tedarik Süresi
- 7 Weeks
- Insulation Height
- 0.748 19.00mm
- Gerilim
- 300V
- Yayın Yılı
- 2000
- Tip
- Header, Female Sockets
- Ambalaj
- Bulk
- ECCN Kodu
- EAR99
- Flammability Rating
- UL94 V-0
- Number Of Ways
- 2
- Header Orientation
- Vertical
- Safety Approval
- CB; CCA; CSA; CUL; EAC; UL
- Nominal Gerilim
- 320V
- Genişlik
- 22.6mm
- Montaj
- Through Hole
- Akım
- 10A
- Fastening Method
- CONNECTOR
- Akım Değeri
- 12A
- Number Of Levels
- 1
- Housing Material
- Polyamide (PA), Nylon
- Contact Tail Length
- 0.142 3.60mm
- RoHS Durumu
- RoHS Compliant
- Voltageiec
- 630V
- Pozisyon Sayısı
- 2
- Kurşunsuz Kodu
- yes
- Renk
- Green
- Max Current Rating
- 12A
- Orientation
- Straight
- Contact Mating Finish
- Tin
- Kurşunsuz
- Lead Free
- Contact Materials
- Copper
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yükseklik
- 12.16mm
- Seri
- COMBICON ICV
