Volume pricing
- 1+ pcs$4.40
- 10+ pcs$4.15
- 100+ pcs$3.92
- 500+ pcs$3.70
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 4 Weeks
- Wire Strip Length
- 7mm
- RoHS Durumu
- RoHS Compliant
- Nominal Gerilim
- 250V
- Akım Değeri
- 12A
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Contact Mating Finish
- Tin
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- COMBICON MSTBT
- Montaj Tipi
- Free Hanging (In-Line)
- Wire Gauge Or Range Awg
- 12-30 AWG
- Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2011
- Connector Type
- Screw
- Akım
- 15A
- Screw Size
- M3
- Ambalaj
- Bulk
- Number Of Ways
- 14
- Wire Cross Section
- 2.5 mm2
- Sıra Sayısı
- 1
- REACH Uyumluluk Kodu
- unknown
- Montaj
- Free Hanging
- Kurşunsuz Kodu
- yes
- Insulation Height
- 0.591 15.00mm
- Plug Wire Entry
- 180°
- Renk
- Green
- Terminal Stili
- Screw - Rising Cage Clamp
- ECCN Kodu
- EAR99
- Wire Gauge Min
- 12 AWG
- Safety Approval
- UL
- Material Flammability Rating
- UL94 V-0
- Housing Material
- Polyamide (PA), Nylon
- Number Of Levels
- 1
- Pozisyon Sayısı
- 14
- Gerilim
- 300V
- Currentiec
- 12A
- Voltageiec
- 630V
- Özellikler
- Retention Latches (Non-Wire Side)
- Number Of Decks
- 1
- Wire Gauge Max
- 30 AWG
