Volume pricing
- 1+ pcs$3.03
- 10+ pcs$2.86
- 100+ pcs$2.70
- 500+ pcs$2.55
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Renk
- Green
- Number Of Decks
- 1
- Seri
- COMBICON MSTBT
- Wire Cross Section
- 2.5 mm2
- Kurşunsuz Kodu
- yes
- Plug Wire Entry
- 180°
- Tip
- Plug, Female Sockets
- Terminal
- Screw
- Genişlik
- 40mm
- Uzunluk
- 40mm
- Material Flammability Rating
- UL94 V-0
- Gerilim
- 300V
- Screw Size
- M3
- Yayın Yılı
- 2010
- Nominal Gerilim
- 250V
- Wire Gauge Min
- 12 AWG
- Yükseklik
- 18.2mm
- Additional Feature
- PA, 94V-0
- Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Awg
- 12-30 AWG
- Akım Değeri
- 12A
- Number Of Contacts
- 8
- Max Current Rating
- 12A
- Insulation Height
- 0.591 15.00mm
- Fabrika Tedarik Süresi
- 4 Weeks
- Wire Strip Length
- 7mm
- Max Supply Voltage
- 250V
- ECCN Kodu
- EAR99
- Terminal Stili
- Screw - Rising Cage Clamp
- Housing Material
- Polyamide (PA), Nylon
- Pitch
- 0.197 5.00mm
- Voltageiec
- 630V
- Connector Type
- Screw, Socket
- Orientation
- Right Angle
- Number Of Ways
- 8
- Contact Plating
- Tin
- Akım
- 12A
- Safety Approval
- UL
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
