Volume pricing
- 1+ pcs$42.76
- 10+ pcs$40.34
- 100+ pcs$38.05
- 500+ pcs$35.90
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Ways
- 19
- Yayın Yılı
- 2011
- Screw Size
- M2.5
- Nominal Gerilim
- 250V
- Wire Gauge Max
- 30 AWG
- Kurşunsuz Kodu
- yes
- Insulation Height
- 0.591 15.00mm
- Akım Değeri
- 12A
- Number Of Levels
- 1
- Wire Strip Length
- 10mm
- Fabrika Tedarik Süresi
- 5 Weeks
- Connector Type
- Screw
- Material Flammability Rating
- UL94 V-0
- Renk
- Green
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Özellikler
- Retention Latches (Non-Wire Side)
- Contact Mating Finish
- Tin
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- HTS Kodu
- 8536.69.40.40
- Flammability Rating
- UL94 V-0
- Pitch
- 0.197 5.00mm
- Weight
- 249.999986g
- Safety Approval
- UL
- Wire Gauge Min
- 12 AWG
- Housing Material
- Polyamide (PA), Nylon
- Plug Wire Entry
- 180°
- Gerilim
- 300V
- Additional Feature
- PA, 94V-0
- Number Of Decks
- 1
- Tip
- Plug, Female Sockets
- Wire Cross Section
- 2.5 mm2
- Terminal Stili
- Screw - Pressure Clip
- Akım
- 15A
- Wire Gauge Or Range Awg
- 12-30 AWG
- Currentiec
- 12A
- Voltageiec
- 630V
- Seri
- COMBICON FRONT-MSTB
- ECCN Kodu
- EAR99
- Montaj
- Free Hanging
