Volume pricing
- 1+ pcs$1.48
- 10+ pcs$1.40
- 100+ pcs$1.32
- 500+ pcs$1.25
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Akım
- 15A
- Material
- Polyamide
- Number Of Contacts
- 2
- RoHS Durumu
- RoHS Compliant
- Seri
- COMBICON FRONT-MSTB
- Wire Gauge Or Range Awg
- 12-30 AWG
- Material Flammability Rating
- UL94 V-0
- Renk
- Green
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Kurşunsuz Kodu
- yes
- REACH Uyumluluk Kodu
- unknown
- Number Of Ways
- 2
- Yayın Yılı
- 2011
- Contact Plating
- Tin
- Yükseklik
- 15mm
- Housing Material
- Polyamide (PA), Nylon
- HTS Kodu
- 8536.69.40.40
- Özellikler
- Retention Latches (Non-Wire Side)
- Pitch
- 0.197 5.00mm
- Flammability Rating
- UL94 V-0
- Terminal Stili
- Screw - Pressure Clip
- Max Current Rating
- 12A
- Tip
- Plug, Female Sockets
- Pozisyon Sayısı
- 2
- Gender
- Female
- Uzunluk
- 10mm
- Montaj
- Cable, Free Hanging, Plug-In
- Orientation
- Straight
- Montaj Tipi
- Free Hanging (In-Line)
- Parça Durumu
- Active
- ECCN Kodu
- EAR99
- Genişlik
- 27.2mm
- Voltageiec
- 630V
- Depth
- 15mm
- Number Of Levels
- 1
- Fabrika Tedarik Süresi
- 4 Weeks
- Connector Type
- Screw, Socket
- Screw Size
- M2.5
- Nominal Gerilim
- 250V
- Wire Gauge Max
- 12 AWG
