Specifications
- Uzunluk
- 15mm
- Montaj
- Cable, Free Hanging
- Montaj Tipi
- Free Hanging (In-Line)
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Orientation
- Straight
- Sıra Sayısı
- 1
- Wire Gauge Or Range Awg
- 20-26 AWG
- Genişlik
- 16.1mm
- Voltageiec
- 320V
- Seri
- COMBICON PTSM
- ECCN Kodu
- EAR99
- Akım
- 5A
- Tip
- Plug, Female Sockets
- Max Current Rating
- 6A
- Onay Kuruluşu
- UL
- Terminal Stili
- Screwless - Spring Cage, Tension Clamp
- Yükseklik
- 5mm
- Kurşunsuz
- Lead Free
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- Pitch
- 0.098 2.50mm
- Flammability Rating
- UL94 V-0
- Wire Gauge Min
- 20 AWG
- Terminal
- Screwless
- Housing Material
- Polyamide (PA), Nylon
- Plug Wire Entry
- 180°
- Gerilim
- 150V
- Number Of Levels
- 1
- Wire Strip Length
- 6mm
- Fabrika Tedarik Süresi
- 7 Weeks
- Connector Type
- Socket
- Depth
- 15mm
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Mm
- 0.14-0.5mm2
- Renk
- Black
- Terminal Sayısı
- 6
- Yayın Yılı
- 2010
- Contact Plating
- Tin
- Nominal Gerilim
- 160V
