Volume pricing
- 1+ pcs$3.52
- 10+ pcs$3.32
- 100+ pcs$3.13
- 500+ pcs$2.96
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Cross Section
- 2.5 mm2
- Akım
- 15A
- Wire Gauge Or Range Awg
- 12-30 AWG
- Seri
- COMBICON MSTB
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2010
- Contact Plating
- Tin
- REACH Uyumluluk Kodu
- unknown
- Number Of Ways
- 13
- Kurşunsuz Kodu
- yes
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Renk
- Green
- Flammability Rating
- UL94 V-0
- Pitch
- 0.200 5.08mm
- Özellikler
- Mating Flange
- HTS Kodu
- 8536.69.40.40
- Housing Material
- Polyamide (PA), Nylon
- Yükseklik
- 18.2mm
- Max Current Rating
- 12A
- Tip
- Plug, Female Sockets
- Terminal Stili
- Screw - Rising Cage Clamp
- Genişlik
- 76.05mm
- Voltageiec
- 630V
- Max Supply Voltage
- 320V
- ECCN Kodu
- EAR99
- Orientation
- Right Angle
- Montaj Tipi
- Free Hanging (In-Line)
- Parça Durumu
- Active
- Uzunluk
- 15mm
- Montaj
- Free Hanging
- Pozisyon Sayısı
- 13
- Wire Gauge Max
- 12 AWG
- Insulation Height
- 0.591 15.00mm
- Akım Değeri
- 12A
- Screw Size
- M3
- Nominal Gerilim
- 250V
- Wire Strip Length
- 7mm
- Fabrika Tedarik Süresi
- 4 Weeks
- Connector Type
- Screw, Socket
