Specifications
- Number Of Contacts
- 4
- Material
- Polyamide
- Wire Cross Section
- 2.5 mm2
- Akım
- 12A
- Wire Gauge Or Range Awg
- 12-30 AWG
- Seri
- COMBICON MSTB
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2010
- Number Of Ways
- 4
- REACH Uyumluluk Kodu
- not_compliant
- Kurşunsuz Kodu
- yes
- Renk
- Green
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Material Flammability Rating
- UL94 V-0
- Currentul
- 15A
- Pitch
- 0.200 5.08mm
- Flammability Rating
- UL94 V-0
- Özellikler
- Mating Flange
- Contact Materials
- Copper
- Housing Material
- Polyamide (PA), Nylon
- Yükseklik
- 18.2mm
- Tip
- Plug, Female Sockets
- Max Current Rating
- 12A
- Terminal Stili
- Screw - Rising Cage Clamp
- Voltageiec
- 630V
- Genişlik
- 30.33mm
- ECCN Kodu
- EAR99
- Orientation
- Right Angle
- Montaj Tipi
- Free Hanging (In-Line)
- Parça Durumu
- Active
- Montaj
- Free Hanging, Panel, Plug-In
- Uzunluk
- 15mm
- Gender
- Female
- Sıra Sayısı
- 1
- Insulation Height
- 0.591 15.00mm
- Akım Değeri
- 12A
- Wire Gauge Max
- 30 AWG
- Nominal Gerilim
- 250V
- Screw Size
- M3
- Connector Type
- Screw, Socket
