Specifications
- Wire Strip Length
- 10mm
- Fabrika Tedarik Süresi
- 5 Weeks
- Connector Type
- Screw
- Number Of Levels
- 1
- Material Flammability Rating
- UL94 V-0
- Renk
- Green
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Yayın Yılı
- 2011
- Number Of Ways
- 11
- Wire Gauge Max
- 12 AWG
- Akım Değeri
- 12A
- Insulation Height
- 1.083 27.51mm
- Kurşunsuz Kodu
- yes
- Screw Size
- M2.5
- Nominal Gerilim
- 250V
- Number Of Decks
- 1
- Additional Feature
- PA, 94V-0
- Weight
- 135.000004g
- Pitch
- 0.200 5.08mm
- Flammability Rating
- UL94 V-0
- Safety Approval
- UL
- Contact Mating Finish
- Tin
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- HTS Kodu
- 8536.69.40.40
- Özellikler
- Mating Flange, Retention Latches (Non-Wire Side)
- Housing Material
- Polyamide (PA), Nylon
- Plug Wire Entry
- 180°
- Gerilim
- 300V
- Wire Gauge Min
- 24 AWG
- Akım
- 15A
- Tip
- Plug, Female Sockets
- Wire Cross Section
- 2.5 mm2
- Terminal Stili
- Screw - Pressure Clip
- Montaj Tipi
- Free Hanging (In-Line)
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Active
- Montaj
- Free Hanging
- Pozisyon Sayısı
- 11
- Sıra Sayısı
- 1
