Specifications
- Material
- Polyamide, Tin
- Number Of Positions Per Level
- 4
- Terminal Stili
- Screw - Rising Cage Clamp
- Tip
- Plug, Female Sockets
- Akım
- 41A
- ECCN Kodu
- EAR99
- Seri
- COMBICON PC
- Genişlik
- 45.71mm
- Voltageiec
- 1kV
- Wire Gauge Or Range Awg
- 8-24 AWG
- Gender
- Female
- Montaj Tipi
- Free Hanging (In-Line)
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Uzunluk
- 35.5mm
- Montaj
- Free Hanging
- Wire Gauge Max
- 24 AWG
- Insulation Height
- 0.776 19.70mm
- Akım Değeri
- 41A
- Screw Size
- M3
- Nominal Gerilim
- 1kV
- Contact Plating
- Tin
- Yayın Yılı
- 2015
- Material Flammability Rating
- UL94 V-0
- Depth
- 19.7mm
- Renk
- Green
- Wire Gauge Or Range Mm
- 0.2-10mm2
- Wire Strip Length
- 10mm
- Connector Type
- Screw, Socket
- Fabrika Tedarik Süresi
- 7 Weeks
- Number Of Levels
- 1
- Housing Material
- Polyamide (PA), Nylon
- Plug Wire Entry
- 180°
- Gerilim
- 600V
- Wire Gauge Min
- 8 AWG
- Terminal
- Screw
- Pitch
- 0.300 7.62mm
- Flammability Rating
- UL94 V-0
- Özellikler
- Mating Flange, Retention Latches (Non-Wire Side)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
