Volume pricing
- 1+ pcs$4.36
- 10+ pcs$4.11
- 100+ pcs$3.88
- 500+ pcs$3.66
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Cross Section
- 2.5 mm2
- Akım
- 15A
- Wire Gauge Or Range Awg
- 12-30 AWG
- Currentiec
- 12A
- Seri
- COMBICON FRONT-MSTB
- RoHS Durumu
- RoHS Compliant
- Number Of Ways
- 7
- Contact Plating
- Tin
- Yayın Yılı
- 2011
- Kurşunsuz Kodu
- yes
- Material Flammability Rating
- UL94 V-0
- Renk
- Green
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- HTS Kodu
- 8536.69.40.40
- Özellikler
- Mating Flange, Retention Latches (Non-Wire Side)
- Flammability Rating
- UL94 V-0
- Pitch
- 0.200 5.08mm
- Housing Material
- Polyamide (PA), Nylon
- Yükseklik
- 27.2mm
- Tip
- Plug, Female Sockets
- Terminal Stili
- Screw - Pressure Clip
- Genişlik
- 45.36mm
- Voltageiec
- 630V
- ECCN Kodu
- EAR99
- Uzunluk
- 15mm
- Montaj
- Free Hanging
- Montaj Tipi
- Free Hanging (In-Line)
- Parça Durumu
- Active
- Sıra Sayısı
- 1
- Pozisyon Sayısı
- 7
- Screw Size
- M2.5
- Nominal Gerilim
- 250V
- Wire Gauge Max
- 30 AWG
- Insulation Height
- 1.083 27.51mm
- Akım Değeri
- 12A
- Number Of Levels
- 1
- Wire Strip Length
- 10mm
- Fabrika Tedarik Süresi
- 4 Weeks
- Connector Type
- Screw, Socket
- Ambalaj
- Bulk
