Volume pricing
- 1+ pcs$2.50
- 10+ pcs$2.36
- 100+ pcs$2.23
- 500+ pcs$2.10
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge Or Range Awg
- 12-30 AWG
- Currentiec
- 12A
- Seri
- COMBICON FRONT-MSTB
- RoHS Durumu
- RoHS Compliant
- Number Of Contacts
- 4
- Number Of Positions Per Level
- 4
- Housing Color
- Green
- Akım
- 12A
- Flammability Rating
- UL94 V-0
- Pitch
- 0.200 5.08mm
- Özellikler
- Mating Flange, Retention Latches (Non-Wire Side)
- Housing Material
- Polyamide (PA), Nylon
- Contact Materials
- Copper
- Yükseklik
- 27.2mm
- Contact Plating
- Tin
- Yayın Yılı
- 2011
- Currentul
- 15A
- Material Flammability Rating
- UL94 V-0
- Renk
- Green
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Genişlik
- 30.12mm
- Voltageiec
- 630V
- Max Supply Voltage
- 250V
- Positions Per Level
- 4
- Orientation
- Straight
- Montaj Tipi
- Free Hanging (In-Line)
- Parça Durumu
- Active
- Uzunluk
- 30.12mm
- Montaj
- Free Hanging, Panel
- Pozisyon Sayısı
- 4
- Sıra Sayısı
- 1
- Max Current Rating
- 12A
- Tip
- Plug, Female Sockets
- Terminal Stili
- Screw - Pressure Clip
- Weight
- 135.000004g
- Ambalaj
- Bulk
- Contact Mating Finish
- Tin
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Plug Wire Entry
- 180°
- Gerilim
- 300V
