Volume pricing
- 1+ pcs$4.61
- 10+ pcs$4.35
- 100+ pcs$4.11
- 500+ pcs$3.87
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Mating Finish
- Tin
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Weight
- 135.000004g
- Safety Approval
- UL
- Wire Gauge Min
- 24 AWG
- Terminal
- Screw
- Plug Wire Entry
- 180°
- Gerilim
- 300V
- Additional Feature
- PA, 94V-0
- Number Of Decks
- 1
- Kurşunsuz
- Lead Free
- Screw Size
- M2.5
- Nominal Gerilim
- 250V
- Wire Gauge Max
- 12 AWG
- Akım Değeri
- 12A
- Insulation Height
- 1.083 27.51mm
- Number Of Levels
- 1
- Wire Strip Length
- 10mm
- Fabrika Tedarik Süresi
- 4 Weeks
- Connector Type
- Screw, Socket
- Genişlik
- 50.44mm
- Voltageiec
- 630V
- ECCN Kodu
- EAR99
- Uzunluk
- 15mm
- Montaj
- Free Hanging, Panel
- Orientation
- Straight
- Montaj Tipi
- Free Hanging (In-Line)
- Parça Durumu
- Active
- Sıra Sayısı
- 1
- Max Current Rating
- 12A
- Tip
- Plug, Female Sockets
- Terminal Stili
- Screw - Pressure Clip
- Özellikler
- Mating Flange, Retention Latches (Non-Wire Side)
- Flammability Rating
- UL94 V-0
- Pitch
- 0.200 5.08mm
- Housing Material
- Polyamide (PA), Nylon
- Contact Materials
- Copper
- Yükseklik
- 27.2mm
- Number Of Ways
- 8
