Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj
- Cable, Free Hanging, Plug-In
- Uzunluk
- 19.7mm
- Orientation
- Straight
- Montaj Tipi
- Free Hanging (In-Line)
- Parça Durumu
- Active
- Sıra Sayısı
- 1
- Gender
- Female
- Voltageiec
- 1kV
- Genişlik
- 38.05mm
- ECCN Kodu
- EAR99
- Max Current Rating
- 41A
- Tip
- Plug, Female Sockets
- Onay Kuruluşu
- UL
- Terminal Stili
- Screw - Rising Cage Clamp
- Number Of Decks
- 1
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Screw
- Wire Gauge Min
- 24 AWG
- Gerilim
- 600V
- Plug Wire Entry
- 180°
- Number Of Levels
- 1
- Fabrika Tedarik Süresi
- 4 Weeks
- Connector Type
- Screw, Socket
- Wire Strip Length
- 10mm
- Depth
- 19.7mm
- Nominal Gerilim
- 1kV
- Screw Size
- M3
- Akım Değeri
- 41A
- Insulation Height
- 0.776 19.70mm
- Wire Gauge Max
- 8 AWG
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Or Range Awg
- 8-24 AWG
- Seri
- COMBICON PC
- Akım
- 41A
- Number Of Contacts
- 5
- Wire Cross Section
- 6 mm2
- Material
- Polyamide
- Yükseklik
- 35.3mm
- Özellikler
- Retention Latches (Non-Wire Side)
