Specifications
- Yükseklik
- 19.7mm
- Kurşunsuz
- Lead Free
- Özellikler
- Retention Latches (Non-Wire Side)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- HTS Kodu
- 8536.69.40.40
- Pitch
- 0.300 7.62mm
- Flammability Rating
- UL94 V-0
- Terminal
- Screw
- Wire Gauge Min
- 8 AWG
- Housing Material
- Polyamide (PA), Nylon
- Plug Wire Entry
- 180°
- Gerilim
- 600V
- Number Of Levels
- 1
- Fabrika Tedarik Süresi
- 7 Weeks
- Connector Type
- Screw, Socket
- Wire Strip Length
- 10mm
- Wire Gauge Or Range Mm
- 0.2-10mm2
- Renk
- Green
- Depth
- 19.7mm
- Material Flammability Rating
- UL94 V-0
- REACH Uyumluluk Kodu
- unknown
- Yayın Yılı
- 2011
- Contact Plating
- Tin
- Nominal Gerilim
- 1kV
- Screw Size
- M3
- Kurşunsuz Kodu
- yes
- Insulation Height
- 0.776 19.70mm
- Akım Değeri
- 41A
- Wire Gauge Max
- 24 AWG
- Uzunluk
- 15.19mm
- Montaj
- Cable, Free Hanging, Plug-In
- Montaj Tipi
- Free Hanging (In-Line)
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Orientation
- Straight
- Gender
- Female
- Wire Gauge Or Range Awg
- 8-24 AWG
- Voltageiec
- 1kV
- Genişlik
- 35.3mm
