Volume pricing
- 1+ pcs$1.64
- 10+ pcs$1.54
- 100+ pcs$1.46
- 500+ pcs$1.37
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Tail Length
- 0.154 3.90mm
- Seri
- COMBICON MSTBV
- ECCN Kodu
- EAR99
- Voltageiec
- 630V
- Genişlik
- 45.72mm
- Sıra Sayısı
- 1
- Uzunluk
- 45.72mm
- Montaj
- Through Hole
- Orientation
- Straight
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Active
- Montaj Tipi
- Through Hole
- Terminal Stili
- Solder
- Number Of Positions Per Level
- 7
- Max Current Rating
- 12A
- Tip
- Header, Male Pins, Shrouded (4 Side)
- Akım
- 12A
- Wire Gauge Min
- 28 AWG
- Housing Material
- Polybutylene Terephthalate (PBT)
- Gerilim
- 300V
- Özellikler
- Mating and Mounting Flange
- HTS Kodu
- 8536.69.40.40
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Safety Approval
- UL
- Flammability Rating
- UL94 V-0
- Pitch
- 0.200 5.08mm
- Weight
- 154.999997g
- Number Of Decks
- 1
- Additional Feature
- PBT, 94V-0
- Kurşunsuz
- Lead Free
- Yükseklik
- 15.9mm
- Nominal Gerilim
- 250V
- Akım Değeri
- 12A
- Insulation Height
- 0.472 12.00mm
- Kurşunsuz Kodu
- yes
- Header Orientation
- Vertical
- Wire Gauge Max
- 12 AWG
- Number Of Ways
- 7
- REACH Uyumluluk Kodu
- unknown
