Specifications
- Connector Type
- Plug
- Fastening Method
- CONNECTOR
- Fabrika Tedarik Süresi
- 7 Weeks
- Min. Çalışma Sıcaklığı
- -40°C
- Number Of Levels
- 1
- Renk
- Green
- Depth
- 8.3mm
- Material Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2010
- Number Of Ways
- 4
- REACH Uyumluluk Kodu
- not_compliant
- Akım Değeri
- 12A
- Insulation Height
- 0.472 12.00mm
- Kurşunsuz Kodu
- yes
- Header Orientation
- Vertical
- Nominal Gerilim
- 250V
- Kurşunsuz
- Lead Free
- Yükseklik
- 15.9mm
- Number Of Decks
- 1
- Safety Approval
- CB; CCA; CSA; CUL; EAC; GL; RS
- Weight
- 154.999997g
- Pitch
- 0.200 5.08mm
- Flammability Rating
- UL94 V-0
- Özellikler
- Mating and Mounting Flange
- Ambalaj
- Bulk
- Contact Mating Finish
- Tin
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Gerilim
- 300V
- Housing Material
- Polybutylene Terephthalate (PBT)
- Contact Materials
- Copper
- Akım
- 12A
- Tip
- Header, Male Pins, Shrouded (4 Side)
- Max Current Rating
- 12A
- Terminal Stili
- Solder
- Number Of Positions Per Level
- 4
- Montaj Tipi
- Through Hole
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Orientation
- Straight
- Uzunluk
- 30.48mm
