Specifications
- Yayın Yılı
- 2011
- Max Current Rating
- 12A
- Safety Approval
- UL; VDE; CSA
- RoHS Durumu
- RoHS Compliant
- Genişlik
- 45.72mm
- Ambalaj
- Bulk
- Currentul
- 15A
- Gerilim
- 300V
- Montaj Tipi
- Through Hole
- Voltageiec
- 400V
- Nominal Gerilim
- 250V
- Uzunluk
- 45.72mm
- Contact Plating
- Tin
- Pozisyon Sayısı
- 7
- Yükseklik
- 12.1mm
- Depth
- 12mm
- Sıra Sayısı
- 1
- Number Of Ways
- 7
- Seri
- COMBICON MSTB
- Number Of Levels
- 1
- Kurşunsuz Kodu
- yes
- Material Flammability Rating
- UL94 V-0
- Orientation
- Right Angle
- Header Orientation
- 90°, Right Angle
- Kurşunsuz
- Lead Free
- Connector Type
- Plug
- Insulation Height
- 0.339 8.61mm
- Number Of Decks
- 1
- Akım Değeri
- 12A
- Housing Material
- Polybutylene Terephthalate (PBT)
- Tip
- Header, Male Pins, Shrouded (4 Side)
- Contact Tail Length
- 0.138 3.50mm
- Pitch
- 0.200 5.08mm
- Additional Feature
- PBT, UL 94V-0
- Montaj
- Through Hole
- Flammability Rating
- UL94 V-0
- Özellikler
- Mating and Mounting Flange
- HTS Kodu
- 8536.69.40.40
- Terminal Stili
- Solder
- Fabrika Tedarik Süresi
- 4 Weeks
