Volume pricing
- 1+ pcs$1.13
- 10+ pcs$1.07
- 100+ pcs$1.01
- 500+ pcs$0.95
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge Or Range Awg
- 12-30 AWG
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Orientation
- Right Angle
- Kurşunsuz
- Lead Free
- Wire Strip Length
- 7mm
- Seri
- COMBICON MSTB
- Kurşunsuz Kodu
- yes
- Nominal Gerilim
- 250V
- Wire Gauge Min
- 12 AWG
- Depth
- 8.3mm
- Yükseklik
- 39.5mm
- Contact Plating
- Tin
- Uzunluk
- 15.24mm
- Max Current Rating
- 12A
- Genişlik
- 61.8mm
- Ambalaj
- Bulk
- Gerilim
- 300V
- Currentul
- 10A
- Gender
- Female
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Screw
- Fabrika Tedarik Süresi
- 7 Weeks
- ECCN Kodu
- EAR99
- Akım
- 12A
- Özellikler
- Retention Latches (Non-Wire Side), Strain Relief
- Wire Cross Section
- 2.5 mm2
- Flammability Rating
- UL94 V-0
- Terminal Stili
- Screw - Rising Cage Clamp
- REACH Uyumluluk Kodu
- not_compliant
- Additional Feature
- PA, 94V-0
- Housing Material
- Polyamide (PA), Nylon
- Number Of Decks
- 1
- Connector Type
- Screw, Socket
- Number Of Ways
- 3
- Onay Kuruluşu
- CB, CSA, UL, VDE
- Wire Gauge Max
- 30 AWG
- Material Flammability Rating
- UL94 V-0
- Number Of Levels
- 1
- Sıra Sayısı
- 1
- Material
- Polyamide
