Specifications
- Uzunluk
- 22mm
- Montaj
- Through Hole
- REACH Uyumluluk Kodu
- unknown
- Max Current Rating
- 12A
- Sıra Sayısı
- 1
- Kurşunsuz
- Lead Free
- Number Of Ways
- 4
- Akım
- 15A
- Ambalaj
- Bulk
- Connector Type
- Socket
- Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2003
- Seri
- COMBICON SMSTBA
- Depth
- 16.5mm
- Montaj Tipi
- Through Hole
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Orientation
- 45 deg
- Yükseklik
- 16.5mm
- Header Orientation
- 45°
- Akım Değeri
- 12A
- RoHS Durumu
- RoHS Compliant
- Nominal Gerilim
- 250V
- Contact Tail Length
- 0.138 3.50mm
- Fabrika Tedarik Süresi
- 4 Weeks
- Genişlik
- 22mm
- Tip
- Header, Male Pins, Shrouded (4 Side)
- Weight
- 3.282988g
- Pitch
- 0.197 5.00mm
- Voltageiec
- 400V
- Number Of Decks
- 1
- Parça Durumu
- Active
- Number Of Levels
- 1
- Pozisyon Sayısı
- 4
- Gerilim
- 300V
- Material Flammability Rating
- UL94 V-0
- Housing Material
- Polyamide (PA), Nylon
- Terminal Stili
- Solder
- ECCN Kodu
- EAR99
- Safety Approval
- UL
- Renk
- Green
