Volume pricing
- 1+ pcs$7.33
- 10+ pcs$6.92
- 100+ pcs$6.52
- 500+ pcs$6.16
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yükseklik
- 21.3mm
- Material Flammability Rating
- UL94 V-0
- Özellikler
- Retention Latches (Non-Wire Side)
- Genişlik
- 25.4mm
- Renk
- Green
- Currentiec
- 12A
- Tip
- Plug, Female Sockets
- Contact Plating
- Tin
- Seri
- COMBICON MSTBP
- ECCN Kodu
- EAR99
- Number Of Levels
- 1
- Insulation Height
- 0.591 15.00mm
- REACH Uyumluluk Kodu
- unknown
- Montaj Tipi
- Free Hanging (In-Line)
- Nominal Gerilim
- 250V
- Kurşunsuz Kodu
- yes
- Number Of Decks
- 1
- Sıra Sayısı
- 1
- Wire Gauge Min
- 24 AWG
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Or Range Awg
- 12-30 AWG
- Number Of Ways
- 5
- Terminal Stili
- Screw - Rising Cage Clamp
- Safety Approval
- UL
- Terminal
- Screw
- Flammability Rating
- UL94 V-0
- Additional Feature
- PA, 94V-0
- Pitch
- 0.200 5.08mm
- Plug Wire Entry
- 180°
- Voltageiec
- 630V
- Wire Gauge Max
- 12 AWG
- Ambalaj
- Bulk
- Wire Strip Length
- 7mm
- Pozisyon Sayısı
- 5
- Gerilim
- 300V
- Montaj
- Free Hanging
- Yayın Yılı
- 2011
- Parça Durumu
- Active
- Connector Type
- Screw, Socket
- Weight
- 128.999997g
