Volume pricing
- 1+ pcs$5.12
- 10+ pcs$4.83
- 100+ pcs$4.56
- 500+ pcs$4.30
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Levels
- 1
- ECCN Kodu
- EAR99
- Seri
- COMBICON MSTBP
- Contact Plating
- Tin
- Tip
- Plug, Female Sockets
- Renk
- Green
- Özellikler
- Retention Latches (Non-Wire Side)
- Genişlik
- 21.3mm
- Material Flammability Rating
- UL94 V-0
- Yükseklik
- 20.32mm
- Safety Approval
- UL
- Terminal Stili
- Screw - Rising Cage Clamp
- Number Of Ways
- 4
- Wire Gauge Or Range Awg
- 12-30 AWG
- RoHS Durumu
- RoHS Compliant
- Sıra Sayısı
- 1
- Wire Gauge Min
- 12 AWG
- Kurşunsuz Kodu
- yes
- Wire Cross Section
- 2.5 mm2
- Number Of Decks
- 1
- Nominal Gerilim
- 250V
- REACH Uyumluluk Kodu
- unknown
- Montaj Tipi
- Free Hanging (In-Line)
- Insulation Height
- 0.591 15.00mm
- Gerilim
- 300V
- Pozisyon Sayısı
- 4
- Wire Strip Length
- 7mm
- Ambalaj
- Bulk
- Voltageiec
- 630V
- Wire Gauge Max
- 30 AWG
- Flammability Rating
- UL94 V-0
- Pitch
- 0.200 5.08mm
- Plug Wire Entry
- 180°
- Terminal
- Screw
- Currentul
- 15A
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Akım
- 12A
- Uzunluk
- 17mm
- Akım Değeri
- 12A
- Screw Size
- M3
