Volume pricing
- 1+ pcs$3.23
- 10+ pcs$3.04
- 100+ pcs$2.87
- 500+ pcs$2.71
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Currentiec
- 12A
- Yükseklik
- 18.2mm
- Renk
- Green
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Number Of Decks
- 1
- Insulation Height
- 0.591 15.00mm
- Montaj Tipi
- Free Hanging (In-Line)
- Number Of Ways
- 10
- Safety Approval
- UL
- Wire Gauge Max
- 30 AWG
- Terminal
- Screw
- Flammability Rating
- UL94 V-2
- Plug Wire Entry
- 180°
- Additional Feature
- PA, 94V-2
- Wire Strip Length
- 7mm
- Connector Type
- Screw, Socket
- Housing Material
- Polyamide (PA), Nylon
- Fabrika Tedarik Süresi
- 4 Weeks
- Parça Durumu
- Active
- Tip
- Plug, Female Sockets
- Material Flammability Rating
- UL94 V-0
- Genişlik
- 74.2mm
- Özellikler
- Retention Latches (Non-Wire Side)
- Number Of Levels
- 1
- Seri
- COMBICON GMSTB
- Contact Mating Finish
- Tin
- Nominal Gerilim
- 400V
- Wire Cross Section
- 2.5 mm2
- REACH Uyumluluk Kodu
- not_compliant
- Number Of Positions Per Level
- 10
- HTS Kodu
- 8536.69.40.40
- Terminal Stili
- Screw - Rising Cage Clamp
- Sıra Sayısı
- 1
- Wire Gauge Min
- 12 AWG
- Contact Materials
- Copper
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Or Range Awg
- 12-30 AWG
- Voltageiec
- 1kV
- Ambalaj
- Bulk
